12V 10Ah Sodium-Ion Starting Battery (YTX17 Replacement)
High-Performance Na-Ion Battery for Motorcycles, ATVs, Marine & Power Sports
The SPIDERWAY 12V 10Ah Sodium-Ion Starting Battery (YTX17 Equivalent) is a next-generation energy solution engineered for high reliability, extreme temperature performance, and long service life. Compared to traditional lead-acid and even lithium batteries, sodium-ion technology offers superior safety, stable discharge, and excellent cold-start capability—making it ideal for motorcycles, ATVs, marine engines, and small vehicles.
Designed with a compact, lightweight structure (only 2.5 kg) and IP65 protection, this battery delivers powerful starting performance while significantly reducing maintenance and lifecycle cost.
Key Selling Points
1. Advanced Sodium-Ion Technology
- No lithium, no cobalt — safer and more sustainable chemistry
- Stable performance across wide temperature ranges
- Improved thermal safety vs lithium-ion batteries
2. Strong Starting Power (High CCA Performance)
- 250 CCA cold cranking amps ensures reliable ignition
- Delivers 1200W peak power (3s) for instant engine start
- Ideal for cold environments and high-load conditions
3. Ultra-Wide Temperature Adaptability
- Charging: -20°C to 50°C
- Discharging: -40°C to 80°C
- Excellent low-temperature starting performance, outperforming traditional batteries
4. Long Cycle Life & Durability
- >3000 cycles @ 70% DOD (25°C)
- Extended service life reduces replacement frequency
- Lower total cost of ownership
5. Smart BMS Protection System
- Built-in intelligent Battery Management System
- 7-layer protection includes:
- Overcharge protection
- Over-discharge protection
- Overcurrent protection
- Short circuit protection
- Temperature protection
6. Fast Charging & High Efficiency
- Fast charging voltage: 14.6V
- Max charging current: 30A
- Low internal resistance (≤18mΩ) improves efficiency
7. Lightweight & Compact Design
- Weight: Approx. 2.5 kg
- Size: 176 × 87 × 155 mm
- Direct replacement for YTX17 series batteries
8. Maintenance-Free Operation
- No acid, no leakage, no routine maintenance
- Long standby stability with low self-discharge
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | YTX17 / PN10-10Ah |
| Battery Type | Sodium-Ion (Na-ion) |
| Nominal Voltage | 12V |
| Nominal Capacity | 10Ah |
| Rated Energy | 120Wh |
| Minimum Capacity | ≥9Ah |
| Max Discharge Power (3s) | 1200W |
| Cold Cranking Amps (CCA) | 250 |
| Internal Resistance | ≤18mΩ |
| Charging Voltage | 14.6V |
| Float Voltage | 14.2V |
| Max Charging Current | 30A |
| Max Discharging Current | ≤30A |
| Cycle Life | >3000 cycles |
| Protection Level | IP65 |
| Weight | ~2.5 kg |
| Dimensions | 176 × 87 × 155 mm |
Application Scenarios
- Motorcycle starting battery replacement (YTX17 equivalent)
- ATV / UTV / off-road vehicles
- Marine engine starter battery
- Small gasoline engine equipment
- Backup power for mobility devices
Why Choose SPIDERWAY Sodium-Ion Batteries
- Factory-direct supply from China’s battery manufacturing hub (Hefei, Anhui)
- Advanced sodium-ion cell technology with stable supply chain
- OEM/ODM customization available
- Designed for global export markets with strict quality standards
FAQ
1. Is sodium-ion battery better than lithium for starting applications?
Yes. Sodium-ion batteries provide better low-temperature performance, higher safety, and stable discharge, making them highly suitable for starting batteries.
2. Can this battery directly replace a YTX17 lead-acid battery?
Yes. It is designed as a drop-in replacement with similar dimensions and improved performance.
3. Does it require a special charger?
No. It is compatible with standard 12V charging systems, but optimized charging improves lifespan.
4. How long does the battery last?
With proper usage, it can achieve 3000+ cycles, significantly longer than lead-acid batteries.
Conclusion
The 12V 10Ah Sodium-Ion Starting Battery (YTX17 Replacement) represents the next evolution in starter battery technology. With high CCA, ultra-wide temperature performance, long cycle life, and maintenance-free operation, it is the ideal solution for modern vehicles and power equipment.
For distributors, OEMs, and B2B buyers, this product delivers a strong competitive advantage in the emerging sodium-ion battery market.
